Manta trawl net, 30 x 15 cm
Manta trawl net designed for surface sampling of microplastics and biological material, featuring stainless steel frame with buoyancy and adjustable towing height.
Explore product sections
About
KC Denmark Manta trawl net model 23.440 is a surface-sampling system used for collecting microplastic particles and other biological materials from the ocean surface. The system consists of a stainless steel frame fitted with a fine-mesh net and side-mounted wings that provide lift, keeping the opening at the water surface. The wings and bridle are adjustable to allow variations in sampling height. The sample cylinder is made of AISI 316 stainless steel and equipped with small buoyancy elements to maintain horizontal position during operation. It includes five windows covered by stainless steel mesh of the same mesh size as the main net.
Features
Highlighted features for Manta trawl net, 30 x 15 cm
Specifications
Manta trawl net, 30 x 15 cm Specifications
- Ordering No.
- 23.440
- Opening
- 30 x 15 cm
- Material
- AISI 316 stainless steel frame
- Standard net mesh size
- 300 µm (other sizes on request)
- Sample cylinder
- 5 mesh-covered windows, same mesh size as main net
- Position control
- Adjustable wings and bridle
- Buoyancy
- Integrated for horizontal stability
Standard Delivery Content
The contents of a standard order of Manta trawl net, 30 x 15 cm
- AISI 316 stainless steel manta frame
- Adjustable wings and towing bridle for lift control
- Nylon net, standard mesh size 300 µm
- Sample cylinder in stainless steel with 5 mesh-covered windows
- Buoyancy system for horizontal operation
Application
Designed for surface water sampling of microplastics, plankton, and small particulate matter. Operates at the water-air interface, efficiently collecting floating debris and organisms.
